Extraction arm DN75, aluminium, 3 joints, 1230 mm, white, wall mounting - Alsident 75-6555-2-5

This extraction arm from the aluminium version of Alsident System 75 removes vapours, fumes and particles at the point of origin, before they spread into the room air. In school science rooms it captures vapours from experiments that place no special demands on chemical resistance. Fitted on a wall bracket, the arm keeps the bench top clear, and its 1230 mm reach covers a standard workstation. Anodised aluminium tubes and white polypropylene (PP) joints are designed for tasks without special demands on chemical resistance or static dissipation.

Benefits

• Self-supporting design: threaded rods and springs sit inside the arm, so the hood is easy to position at the source
• Dismantled without tools in a few steps, maintenance is limited to cleaning as needed
• Anodised aluminium tubes, impact-resistant PP plastic parts, threaded rods and springs in acid-resistant stainless steel AISI 316L
• Wall mounting keeps bench top and floor clear

Specifications

Applications

• School and university science rooms
• Laser technology
• Machinery industry
• Food industry

Compatibility and scope of delivery

• Matching System 75 hoods: 1-7524-5 (round Ø200), 1-7528-5 (round Ø280), 1-7535-5 (round Ø385), 1-753324-5 (330 x 240 mm), 1-7526-5 (suction nozzle 250 mm)
• Bracket: wall bracket 2-195 (open), 2-195-10-5 (closed) or 2-195-10-22 (stainless steel AISI 316L)
• Guard grille 5-17, reducing socket 4-8075 (80/75 mm) or 4-10075 (100/75 mm) to the exhaust duct
• Scope of delivery: extraction arm without hood and bracket, order both separately
