Extraction arm DN50, 2 joints, 430 mm, red, wall/ceiling mount - Alsident 50-27-3-4

The extraction arm 50-27-3-4 mounts on a wall or ceiling and keeps the work surface free. With 430 mm reach and 2 joints it captures soldering fumes at electronics workstations close to the workpiece in tight spaces, at airflows of 45 to 85 m³/h.

Benefits

• 430 mm reach with 2 joints: hood positioned close to the workpiece in tight spaces, measured from the centre of the hood opening
• Self-supporting design with threaded rods and springs inside the tube: easy to move and to bring to the source
• Anodised aluminium tubes, impact-resistant polypropylene joints in red
• Maintenance is limited to cleaning as needed, and the arm comes apart without tools
• One base number for wall and ceiling: fits a wall bracket or a base box

Specifications

Applications

• Soldering and rework stations in electronics production
• Laboratories in research, quality control and training
• Dental labs and dental practices

Compatibility and scope of delivery

• System 50 hoods, e.g. nozzle 1-5021 or hood 1-5024-4 or 1-5028-4
• Protective grid 5-16 against foreign objects being drawn in
• Wall bracket 2-195 (white) or 2-195-050 (black), for ceilings base boxes from 2-250 to 2-2500
• Scope of delivery: extraction arm, hood and bracket are ordered separately
