Stainless Steel Insert Basket for RK/DT 1028 - Bandelin Sonorex K 29 EM
Stainless steel insert basket for the RK 1028/H, DT 1028/H and DT 1058 M baths. It keeps the items in the optimum cavitation zone and protects the oscillating tank from abrasion, with a 10 kg load capacity. Medical Device Class I.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The K 29 EM is a stainless steel insert basket that holds the items in the RK 1028/H, DT 1028/H and DT 1058 M baths. During ultrasonic operation nothing may rest on the tank floor, as this causes abrasion between the items and the oscillating tank. The basket keeps the items in the optimum cavitation zone, about 1 to 2 cm above the floor.
Benefits
- Protects the oscillating tank from abrasion by the items
- Positions the items in the optimum cavitation field
- Convenient loading and removal, also for rinsing
- No contact with the cleaning liquid when handling
- Corrosion-resistant stainless steel, 10 kg load capacity
Applications
The basket holds instruments and components and allows even, material-friendly cleaning in clinics, labs and workshops. After operation the items and basket can be removed without contact with the cleaning liquid. The basket is marked as a Class I Medical Device and is CE compliant.
Compatible with the RK 1028/H, DT 1028/H and DT 1058 M ultrasonic baths and with the ZE 1031/1032/1058/1059 DT inserts.
Technical data
| Order no. | 688 |
|---|---|
| Inner dimensions (L×W×D) | 470 × 240 × 45 mm |
| Tank material | Stainless steel |
| Load capacity | 10 kg |
| Weight | 1.948 kg |
| Manufacturer | Bandelin |
| Manufacturer Nr. | 688 |
| HS-Code | 84799080 |
| GPSR manufacturer information | BANDELIN electronic GmbH & Co. KG, Heinrichstraße 3-4, DE-12207 Berlin, bandelin.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
Downloads
Datasheet
Brochure
CAD Data
Other
