ESD SMD Tweezers Ultra Fine 120 mm Form 7a, 40 Degree Bend, 0.2 mm Tip, Dissipative - Bernstein 5-055-UF-13

Gripping the finest SMD components under a microscope inside the EPA calls for a precise tip and a dissipative surface. The ESD tweezers 5-055-UF-13 combine a 40 degree sickle-shaped bend tapering to a 0.2 mm tip, tolerance +/-0.05 mm, with a black ESD coating.

Benefits

• The ESD coating with a surface resistance of 10^6 to 10^9 ohm protects components in the EPA.
• A 0.2 mm fine tip with +/-0.05 mm tolerance reliably grips the smallest SMD components.
• The 40 degree sickle-shaped bend, approximately 35 mm long, allows sideways access under the microscope.
• Antimagnetic SA stainless steel does not detune sensitive components or assemblies.
• The matt polished, glare-free surface reduces reflections while working under the microscope.

Technical Data

Application

• Precise gripping, holding, and positioning of ESD-sensitive SMD components in the EPA under the microscope.
• Placement and rework on electrical and electronic assemblies.
• Equipping robotics for pick-and-place work thanks to the repeatable 0.2 mm tip tolerance.

Standards and Delivery Data

• DIN EN 61340-5-1 (EPA suitability through dissipative ESD coating)
• EAN 4250838516488
• Customs tariff number 82032000
• Country of origin Italy
