ESD Protective Jaws Plastic 50 mm, Dissipative 10^4 to 10^6 Ohm (Pair) - Bernstein 9-900-E50-ESD
The 9-900-E50-ESD protective jaws are made of dissipative plastic with a resistance between 10^4 and 10^6 Ohm, protecting workpieces in a 50 mm wide vise while staying ESD safe. The smooth back is self-adhesive, the waffle-pattern front ensures a secure hold. Fits the ball-and-socket vise SPANNFIX 9-205 ESD.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For ESD-controlled production, the 9-900-E50-ESD protective jaw made of dissipative plastic shields sensitive components in a 50 mm wide vise, with a resistance between 10^4 and 10^6 Ohm.
Advantages
- Dissipative plastic with a resistance of 10^4 to 10^6 Ohm for ESD-safe clamping
- Smooth back for gluing, self-installed within minutes
- Waffle pattern structure on the front for a strong hold and good fixation of clamped parts
- Compact dimensions of approx. 50 x 25 x 3.3 mm matching 50 mm jaw width
- Light weight of 9 g per pair
Application
The protective jaws fit the ball-and-socket vise SPANNFIX 9-205 and 9-205 ESD, whose head can be tilted in any direction thanks to a high-quality ball joint and individually locked using an adjusting screw. Suitable for electrostatic discharge sensitive devices (EPA) in electronics and precision assembly.
Standards and Supply Data
- EAN 4250838527958
- Customs tariff number 39269097
- Country of origin Germany
Technical data
| Feature | Value |
|---|---|
| Suitable for | Vise jaws width 50 mm |
| Mounting | Smooth surface to stick on yourself |
| Surface | Waffle pattern for a strong hold |
| Material | Dissipative plastic (ESD safe) |
| Resistance | 10^4 to 10^6 Ohm |
| Color | black |
| Packing unit | pair |
| Dimensions | approx. 50 x 25 x 3.3 mm |
| Weight | 9 g |
| Manufacturer | Bernstein |
| Manufacturer Nr. | 9-900-E50-ESD |
| EAN | 4250838527958 |
| HS-Code | 39269097 |
| GPSR manufacturer information | BERNSTEIN Werkzeugfabrik Industriehof Trecknase 1 DE-42897 Remscheid www.bernstein-werkzeuge.de |
| Condition of article | New |
| Article authenticity | Original product |
| ESD version | ESD (antistatic) |
