Planetary gearbox 3GE27, size 3, ratio 27 - Bosch Rexroth 0608720053

On size 3 spindles every millimetre of height often counts. With 65.5 mm installation length the 3GE27 planetary gearbox is 16 mm shorter than the 3GE67 and weighs only 0.35 kg net. Its ratio of 27 delivers noticeably more output speed than the high-ratio version, and typical efficiency is 0.93.

Benefits

• 65.5 mm installation length, the shorter gearbox option in size 3
• Ratio of 27 for fast rundown phases
• Typical efficiency 0.93
• Light module at 0.35 kg net weight

Specifications

Applications

• Size 3 spindles with limited height
• Multi-spindle heads where cycle time comes first

System compatibility

• Rexroth Tightening System 350, size 3
• EC303 EC motor
• For higher torques: 3GE67
