TASS brake test element TR2, 10 to 20 Nm - Bosch Rexroth 3609438124

Short test cycles instead of flying blind in production: the TASS TR2 brake test element for 10 to 20 Nm makes daily spindle checks practical, because the spindle stays installed and three parameters are checked in one pass. As the second size of the TASS elements, TR2 has a 30 mm width across flats and a length l3 of 176.5 mm, and weighs 1.2 kg.

Benefits

• Immediate feedback after the test run, so release or readjustment can be decided on the spot
• Suitable for short intervals, for example daily, so deviations are detected before they carry over into many joints
• Three parameters in one pass: two torque values, angle and linearity, no second test setup required
• Characteristic values M1 10 Nm and M2 20 Nm cover the working range stated in the designation, M3 is specified as 25 Nm
• Size TR2 at 1.2 kg with a 30 mm width across flats, easy to handle at the station

Specifications

Applications

• Regular checks of fixtured nutrunners and spindles with target values from 10 to 20 Nm
• Testing and setting nutrunners before production start or after work on the spindle
• Daily validation of tightening stations without removing the spindle

System compatibility

• TASS (Tool Analysis and Setup System) by Bosch Rexroth, size TR2 with elements from 6 to 35 Nm
• Adapters match the interface to the joint (hex socket, external hex, Torx, internal thread)
• TASS FIX TR2 fixture (Bosch Rexroth 3609438002) for fixed mounting at the test station
