TASS brake test element TR3, 50 to 100 Nm - Bosch Rexroth 3609438138

With 50 to 100 Nm, the TASS TR3 brake test element covers a narrow torque band and suits spindles whose target value lies within it. Testing takes place in the installed state, two torques, angle and linearity in one pass. As the third size of the TASS elements, TR3 has a 32 mm width across flats and a length l3 of 226.5 mm, and weighs 1.75 kg.

Benefits

• Characteristic values M1 50 Nm and M2 100 Nm cover the working range stated in the designation, M3 is specified as 125 Nm
• Testing in the installed state, the spindle stays in the machine and the cycle is barely interrupted
• Three parameters in one pass: two torque values, angle and linearity, no second test setup required
• Suitable for short intervals, for example daily, so deviations are detected before they carry over into many joints
• Size TR3 at 1.75 kg with a 32 mm width across flats, easy to handle at the station

Specifications

Applications

• Regular checks of fixtured nutrunners and spindles with target values from 50 to 100 Nm
• Testing and setting nutrunners before production start or after work on the spindle
• Daily validation of tightening stations without removing the spindle

System compatibility

• TASS (Tool Analysis and Setup System) by Bosch Rexroth, size TR3 with elements from 20 to 100 Nm
• Adapters match the interface to the joint (hex socket, external hex, Torx, internal thread)
• TASS FIX TR3 fixture (Bosch Rexroth 3609438003) for fixed mounting at the test station
