Bosch Rexroth 3842242351. PE 2/XP BG2 positioning unit

Bosch Rexroth
€4,458.59
Excl. 19% VAT , excl. Shipping Cost
Article
BRR-3842242351

Manufacturer Nr.
3842242351
PE 2/XP BG2 positioning unit
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price

PE 2/XP BG2 positioning unit

  • Positions a Workpiece pallet in a processing station with especially high vertical process force requirements (100 kN/60 kN), such as those needed for press-fit or riveting work
  • Mounting in force cells, positive force introduction
  • WT lift above transportation level, approx. 3 mm
  • Can be combined with WT 2 workpiece pallets



ESD

yes

Permissible vertical process force [N]

100

Lift of WT over conveyor medium [h0]

3

Workpiece pallet total weight [mG] [kg]

30

Repetition accuracy

0,05

Delivery information

Fully assembled

Workpiece pallet width [bWT] [mm]

240

Length in direction of transport [lT] [mm]

240

Required accessories

Anvil plate for standard sizes from 160 x 160 mm to 320 x 240 mm,Anvil plate for 320 x 240 mm Workpiece pallet ,Positioning pins, round and flat-sided h = 30 mm for standard anvil plate h = 21 mm for special designs,Stop gate VE 2/,2x M12x70 and M12

Weight [kg]

28.55
More Information
Execution TEC
Manufacturer Nr. 3842242351
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.009900
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
