The PE 2 positioning unit positions and locks WT 2 workpiece pallets precisely within the TS 2plus transfer system. It lifts the pallet above the conveyor medium and holds it with a repetition accuracy of ±0,1 mm. The ESD version suits the assembly of electrostatically sensitive components.
Positioning unit PE 2 ESD, 400 x 320 mm, for TS 2plus - Bosch Rexroth 3842504717
BOSCH REXROTH
Original product
Net price (excl. VAT)
€1,244.72
Item
BRR-3842504717
Manufacturer no.
3842504717
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842504717
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842504717
Frequently Bought Together
-
This Item:
€1,244.72
-
PE 2 positioning unit LT320 x B160, ESD - Bosch Rexroth 3842504708
€1,072.96
-
Housing Element for HD 2/H Conveyor, 240/320, 180° - Bosch Rexroth 3842552602
€606.11
Total price
The PE 2 positioning unit positions and locks WT 2 workpiece pallets within the Bosch Rexroth TS 2plus transfer system. It lifts the pallet above the conveyor medium and fixes it accurately at processing and handling stations. The ESD version is designed for the assembly of electrostatically sensitive components.
- Repetition accuracy ±0,1 mm for process-reliable positioning
- Can be combined with WT 2/LS, no special LS version required
- Supplied fully assembled, including fastening material
Technical data
| ESD | yes |
| Thread size | G1/8" |
| Track width in direction of transport [b] | 320 mm |
| Length in direction of transport [lT] | 400 mm |
| Required compressed air connection | 4 - 6 bar |
| Repetition accuracy | ±0,1 mm |
| Permissible vertical process force | 300 N |
| Lift of WT over conveyor medium [h0] | 2,5 mm |
| Workpiece pallet total weight [mG] | 30 kg |
| Scope of delivery | incl. fastening material |
| Delivery information | fully assembled |
| Required accessories | Stop gate VE 2/... |
| Recommended accessories | Position sensing kit for PE 2 |
| Weight | 4,474 kg |
| Weight | 0.100000 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | 3842504717 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
