Housing Element for HD 2/H Transfer System, 640/800 mm, 180° - Bosch Rexroth 3842552619
Protective housing element for the Bosch Rexroth HD 2/H transfer system, sized for a 640 mm workpiece pallet length and 800 mm width, with a 180° opening angle. Guards drives, guides and mechanics below the conveying level against contamination and unintended contact. Protection above the conveying level must be planned separately for each application.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The housing element 3842552619 fits the Bosch Rexroth HD 2/H transfer system and provides reliable enclosure of the area below the conveying level for a 640 mm x 800 mm workpiece pallet. It protects drives, guides and mechanical components against chips, dirt and accidental interference from outside.
- Matched to workpiece pallet size 640 mm x 800 mm (lWT x bWT)
- 180° opening angle for full lateral access during maintenance
- Encloses the zone below the conveying level - no separate base protection required
- Protection above the conveying level must be configured individually per application
- Combines directly with other housing element variants across the HD 2/H range
Technical data
| Parameter | Value |
|---|---|
| Article number | 3842552619 |
| System | HD 2/H |
| Workpiece pallet length (lWT) | 640 mm |
| Workpiece pallet width (bWT) | 800 mm |
| Opening angle | 180° |
| Weight | 9.12 kg |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | 3842552619 |
| HS-Code | 73089059 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
