The PE 2/X positioning unit locates and holds workpiece pallets in the TS 2plus transfer system with a repetition accuracy of ±0.1 mm. Pneumatically operated at 4-6 bar, it lifts the pallet 3 mm above the conveyor medium and withstands vertical process forces up to 3500 N. Available in five lengths from 480 to 1200 mm, ESD-safe and fully assembled.
Positioning Unit PE 2/X for Transfer System TS 2plus, ESD-Safe - Bosch Rexroth 3842998324
BOSCH REXROTH Original product
Net price (excl. VAT)
€3,474.76
Item BRR-3842998324
Manufacturer no. 3842998324
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998324
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842998324
Frequently Bought Together
- This Item: €3,474.76
- Positioning Unit PE 2/LS for Transfer System TS 2plus, Track Width 240 mm - Bosch Rexroth 3842563404 €1,612.52
- Lift-rotate unit HD 2, b160 lT320, 180° rotation, ESD - Bosch Rexroth 3842525854 €4,907.61
Total price
The PE 2/X positioning unit is a pneumatic positioning and orientation component for the Bosch Rexroth TS 2plus transfer system. It raises the workpiece pallet precisely 3 mm above the conveyor medium and holds it with a repetition accuracy of ±0.1 mm - designed for demanding assembly processes with vertical process forces up to 3500 N.
- Repetition accuracy ±0.1 mm for reproducible machining and assembly positions
- ESD-safe design for electrostatically sensitive assemblies
- Pneumatic operation at 4-6 bar, 8 mm straight push-in fitting
- Supports workpiece pallet total weights up to 100 kg
- Five standard lengths (480, 640, 800, 1040, 1200 mm) for flexible system layouts
- Supplied fully assembled, including fastening material and switch bracket for M12 sensors (top position inquiry)
Technical data
| Specification | Value |
|---|---|
| Repetition accuracy | ±0.1 mm |
| Lift of workpiece pallet above conveyor (h0) | 3 mm |
| Permissible vertical process force | 3500 N |
| Workpiece pallet total weight (mG) | max. 100 kg |
| Compressed air pmin | 4 bar |
| Compressed air pmax | 6 bar |
| Pneumatic straight connection | 8 mm dia. |
| Length in direction of transport (lT) | 480, 640, 800, 1040, 1200 mm |
| ESD-safe | yes |
| Scope of delivery | Incl. fastening material, switch bracket for M12 sensors (top position inquiry) |
| Delivery condition | Fully assembled |
| Required accessories | Stop gate VE 2/... |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842998324 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
