Four-track longitudinal conveyor for glass modules and panels at process temperatures up to 160 °C, designed for use directly after lamination. The Viton-coated toothed belt delivers a high friction coefficient that prevents module slippage and supports high acceleration and deceleration rates. Track spacing is individually adjustable; the section is rated for cleanroom class 7 per ISO 14644-1.
Belt Section CSS/NT-4 with 4 Tracks, Viton Toothed Belt, up to 160 °C - Bosch Rexroth 3842998634
BOSCH REXROTH
Original product
Net price (excl. VAT)
€3,985.40
Item
BRR-3842998634
Manufacturer no.
3842998634
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998634
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842998634
Frequently Bought Together
The CSS/NT-4 belt section is a four-track longitudinal conveyor for glass modules and panels exposed to process temperatures up to 160 °C - suitable as a transport system immediately after lamination. The special textile toothed belt with Viton coating provides a high friction coefficient, preventing module slippage and allowing high acceleration and deceleration values without accumulation operation.
- Four tracks for uniform support across the full module width; track spacings b1 to b4 individually configurable (min. 180 mm, max. 1000 mm per track)
- Permissible load: max. 0.3 kg/cm support surface length and max. 60 kg per track, max. 120 kg per belt section
- Reversible operation up to 1500 mm section length; not intended for accumulation operation
- Dynamic belt tensioner automatically compensates belt stretching caused by temperature exposure
- Continuous toothed belts can be replaced from the side without realignment - including inner tracks, via couplings on the hexagonal shaft
- Gear motors suitable for operation with frequency converter; motor supplied separately
- Cleanroom-compatible up to class 7 per ISO 14644-1
- Price advantage when ordering selected standard lengths; shorter delivery times for replacement toothed belts
Technical data
| Parameter | Value |
|---|---|
| Number of tracks | 4 |
| Length min. (L min) | 550 mm |
| Length max. (l max) | 3000 mm |
| Track width per track min. (b1-b4 min) | 180 mm |
| Track width per track max. (b1-b4 max) | 1000 mm |
| Total width in transport direction min. (b min) | 255 mm |
| Total width in transport direction max. (b max) | 2300 mm |
| Permissible load per track | max. 0.3 kg/cm and max. 60 kg |
| Permissible load per belt section | max. 120 kg |
| Max. temperature of transported goods | 160 °C |
| Belt type | Special textile toothed belt with Viton coating |
| Cleanroom class | ISO 14644-1 class 7 |
| Motor delivery | Separate (not included) |
| Length deviation / note | +/-0.5 mm; bxmin = 350 mm for motor mounting between the tracks |
| Recommended accessories | Frames SFS, leg set SZS/N, frequency converter FU, toothed belt tensioner tool |
| Weight (section) | Product-specific, catalogue value 0 kg (configurable) |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842998634 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
