The Curve KU 1/360 closes the workpiece carrier loop in the Rexroth TS 1 transfer system using a single shared drive for both turntables and the connected belt sections. Built-in accumulation capability eliminates the need for complex control systems. Suitable for ESD environments (EPA) and cleanrooms up to ISO Class 7.
Curve KU 1/360 for TS 1 Transfer System, 360° Circuit, ESD-Suitable - Bosch Rexroth 3842999988
BOSCH REXROTH
Original product
Net price (excl. VAT)
€7,968.30
Item
BRR-3842999988
Manufacturer no.
3842999988
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842999988
Country of originGermany
Customs tariff number84283300
ConditionNew
Article
BRR-3842999988
Frequently Bought Together
-
This Item:
€7,968.30
-
Drive Kit BS 1 for Curve KE 1/O-90, ESD - Bosch Rexroth 3842537619
€208.85
-
Curve Module CU 1/90 for 90° Workpiece Carrier Transport, ESD-Suitable - Bosch Rexroth 3842998287
€2,975.30
Total price
The Curve KU 1/360 completes the workpiece carrier circuit in the Rexroth TS 1 transfer system, enabling a cost-effective closed loop with just one drive unit. The integrated accumulation function allows operation without elaborate control technology. The curve is rated for ESD applications (EPA-compliant), cleanrooms to ISO Class 7, and dry-room environments below 1% relative humidity.
- Closed workpiece carrier circuit with a single drive - low-cost system layout
- Integrated drive shared by both turntables and all mounted belt sections
- Section load up to 30 kg in accumulation mode when a second drive is fitted (AE = 2)
- Track widths 80, 120 and 160 mm; belt section length freely selectable from 150 to 5000 mm
- ESD-suitable (yes), cleanroom class ISO 7, dry room below 1% RH
- Scope of delivery: complete curve module with drive, partially assembled
Technical data
| Parameter | Value |
|---|---|
| Article number | 3842999988 |
| Curve type | KU 1/360 |
| Belt distance | a = 135 mm |
| Track widths b | 80 / 120 / 160 mm |
| Dimension f | 165 / 203 / 243 mm |
| Dimension g | 422 / 505 / 580 mm |
| Section length L1 | 150 to 5000 mm (freely selectable) |
| Max. section load in accumulation, 1 drive | 24 kg |
| Max. section load in accumulation, 2 drives | 30 kg |
| Nominal speed vN | 0 / 6 / 9 / 12 / 15 / 18 m/min |
| Curve direction KR | right (R) or left (L) |
| Motor mounting MA | external (A) |
| Drive units AE | 1 or 2 |
| ESD-suitable | yes |
| Cleanroom class | ISO Class 7 |
| Dry room | below 1% RH |
| Energy efficiency | Rexroth 4EE |
| Scope of delivery | Complete curve module with drive, partially assembled |
| Weight | 0.0099 kg (positional item; installed system weight is application-dependent) |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842999988 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84283300 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
