Module SMS-080-P10-800 - Bosch Rexroth R02681H016
Module SMS-080-P10-800 by Bosch Rexroth, material number R02681H016. Size SMS-080.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Module SMS-080-P10-800 by Bosch Rexroth, material number R02681H016. Size SMS-080. Permissible values are up to 0.45 m/s travel speed and 3 m/s² acceleration. The weight is 8.53 kg.
Technical data
| Lead | 10 mm |
|---|---|
| Permissible overhang C at maximum payload - wall mounting | 115 mm |
| Maximum permissible linear speed vmax | 0.45 m/s |
| Permissible overhang B at maximum payload - wall mounting | 19 mm |
| Permissible overhang C at maximum payload vertical | 133 mm |
| Permissible overhang A at maximum payload vertical | 133 mm |
| Permissible overhang A at maximum payload - wall mounting | 27 mm |
| Nominal size | SMS-080 |
| Maximum stroke | 800 mm |
| Maximum payload - wall mounting | 88 kg |
| Repeatability | <prefix>±</prefix>0.005<suffix></suffix> mm |
| Permissible overhang B at maximum payload horizontal | 19 mm |
| Permissible overhang C at maximum payload horizontal | 27 mm |
| Module height | 78 mm |
| Maximum drive torque | 2.2 Nm |
| Permissible overhang A at maximum payload horizontal | 115 mm |
| Maximum payload horizontal | 88 kg |
| Module width | 82 mm |
| Maximum payload vertical | 21 kg |
| Overall length Ltot | 1018 mm |
| Maximum acceleration rate amax | 3 m/s² |
| Weight | 8.53 kg |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | R02681H016 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
