Module SMS-080-P20-1000 by Bosch Rexroth, material number R02681H070. Size SMS-080.
Module SMS-080-P20-1000 - Bosch Rexroth R02681H070
BOSCH REXROTH
Original product
Net price (excl. VAT)
€1,900.03
Item
BRR-R02681H070
Manufacturer no.
R02681H070
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R02681H070
Country of originGermany
ConditionNew
Article
BRR-R02681H070
Frequently Bought Together
-
This Item:
€1,900.03
-
Schalterplatte BG - Bosch Rexroth R037530021
€10.16
-
Clamping piece ckx 20-145 - Bosch Rexroth R037551002
€10.09
Total price
Module SMS-080-P20-1000 by Bosch Rexroth, material number R02681H070. Size SMS-080. Permissible values are up to 0.53 m/s travel speed and 6 m/s² acceleration. The weight is 9.85 kg.
Technical data
| Lead | 20 mm |
|---|---|
| Permissible overhang C at maximum payload - wall mounting | 112 mm |
| Maximum permissible linear speed vmax | 0.53 m/s |
| Permissible overhang B at maximum payload - wall mounting | 40 mm |
| Permissible overhang C at maximum payload vertical | 247 mm |
| Permissible overhang A at maximum payload vertical | 247 mm |
| Permissible overhang A at maximum payload - wall mounting | 47 mm |
| Nominal size | SMS-080 |
| Maximum stroke | 1000 mm |
| Maximum payload - wall mounting | 40 kg |
| Repeatability | <prefix>±</prefix>0.005<suffix></suffix> mm |
| Permissible overhang B at maximum payload horizontal | 40 mm |
| Permissible overhang C at maximum payload horizontal | 47 mm |
| Module height | 78 mm |
| Maximum drive torque | 2.2 Nm |
| Permissible overhang A at maximum payload horizontal | 112 mm |
| Maximum payload horizontal | 40 kg |
| Module width | 82 mm |
| Maximum payload vertical | 8 kg |
| Overall length Ltot | 1218 mm |
| Maximum acceleration rate amax | 6 m/s² |
| Weight | 9.85 kg |
| Manufacturer Nr. | R02681H070 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
