Module SMS-080-P20-1200 by Bosch Rexroth, material number R02681H074. Size SMS-080.
Module SMS-080-P20-1200 - Bosch Rexroth R02681H074
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,026.80
Item
BRR-R02681H074
Manufacturer no.
R02681H074
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R02681H074
Country of originGermany
ConditionNew
Article
BRR-R02681H074
Frequently Bought Together
-
This Item:
€2,026.80
-
Proximity switch BES517-352-NO-C-03 - Bosch Rexroth R345304002
€96.67
-
Switch MLR110-NN-3 /NPN-CLO - Bosch Rexroth R039980217
€299.49
Total price
Module SMS-080-P20-1200 by Bosch Rexroth, material number R02681H074. Size SMS-080. Permissible values are up to 0.36 m/s travel speed and 6 m/s² acceleration. The weight is 11.53 kg.
Technical data
| Lead | 20 mm |
|---|---|
| Permissible overhang C at maximum payload - wall mounting | 112 mm |
| Maximum permissible linear speed vmax | 0.36 m/s |
| Permissible overhang B at maximum payload - wall mounting | 40 mm |
| Permissible overhang C at maximum payload vertical | 247 mm |
| Permissible overhang A at maximum payload vertical | 247 mm |
| Permissible overhang A at maximum payload - wall mounting | 47 mm |
| Nominal size | SMS-080 |
| Maximum stroke | 1200 mm |
| Maximum payload - wall mounting | 40 kg |
| Repeatability | <prefix>±</prefix>0.005<suffix></suffix> mm |
| Permissible overhang B at maximum payload horizontal | 40 mm |
| Permissible overhang C at maximum payload horizontal | 47 mm |
| Module height | 78 mm |
| Maximum drive torque | 2.2 Nm |
| Permissible overhang A at maximum payload horizontal | 112 mm |
| Maximum payload horizontal | 40 kg |
| Module width | 82 mm |
| Maximum payload vertical | 8 kg |
| Overall length Ltot | 1418 mm |
| Maximum acceleration rate amax | 6 m/s² |
| Weight | 11.53 kg |
| Manufacturer Nr. | R02681H074 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
