Standard linear bushing KBM-4-NR for 4 mm shaft - Bosch Rexroth R060000430

Bosch Rexroth ✓ Original product Brand new Made in Germany

Standard linear bushing KBM-4-NR by Bosch Rexroth for shafts of 4 mm diameter. Dynamic load capacity 80 N, static load capacity 85 N. Without wiper seals, not lubricated, weight 0.01 kg.

Net
€54.74
excl. VAT
Item BRR-R060000430
Manufacturer no. R060000430
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Building a linear guide on hardened precision shafts calls for a bearing with a defined load capacity and low friction. The standard linear bushing KBM-4-NR runs on shafts of 4 mm diameter and reaches a dynamic load capacity of 80 N with a static load capacity of 85 N. Weight: 0.01 kg.

Benefits

  • Load capacity: dynamic 70 N to 80 N, static 60 N to 85 N, depending on load direction relative to the ball rows
  • Dynamics: up to 2.5 m/s, acceleration up to 100 m/s²
  • Sealing and lubrication: without wiper seals, not lubricated
  • Design: Closed, series Standard (metal)
  • Clearance: Shaft radial clearance h6 +14 µm
  • Material: Corrosion-resistant

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR060000430
Type designationKBM-4-NR
Friction coefficient μ0.001 ... 0.004
LubricationNot lubricated
Maximum permissible linear speed vmax2.5 m/s
Length of linear bushing12 mm
SeriesStandard (metal)
Shaft radial clearance h6+14 µm
Maximum dynamic load capacity Cmax80 N
Rows of balls4
Working bore diameter tolerance+8 µm
Maximum acceleration rate amax100 m/s²
Outer diameter D8 mm
Minimum static load capacity C0min60 N
Shaft diameter d4 mm
Minimum dynamic load capacity Cmin70 N
Maximum static load capacity C0max85 N
Format of linear bushingsClosed
VersionCorrosion-resistant
SealWithout wiper seals
Permissible ambient temperature (min. ... max.)-10 °C ... +80 °C
Weight0.01 kg
Manufacturer Nr.R060000430
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
