Ball bushings
Ball bushing guides
Bosch Rexroth ball bushings (Compact-KB series KBC) are rolling element bearings for linear guidance on cylindrical shafts. The KBC-10 series covers a shaft diameter of 10 mm in four versions: KBC-10 (standard), KBC-10-D (open one side for carriage systems), KBC-10-DD (open both sides), and KBC-10-NR (without retaining clip). The Compact-KB design achieves a particularly short overall length at load ratings comparable to conventional ball bushings.
| Type | Article no. | Feature |
|---|---|---|
| KBC-10 | R065801000 | Standard version, closed |
| KBC-10-D | R065811040 | Open one side |
| KBC-10-D-NR | R065811030 | Open one side, without retaining clip |
| KBC-10-DD | R065821040 | Open both sides |
| KBC-10-DD-NR | R065821030 | Open both sides, without retaining clip |
Typical applications: Linear carriage guides on round shafts in handling modules and small automation systems, guide bearings in dispensing and filling equipment, replacement of conventional ball bushings in space-critical retrofits, linear guides in printing devices and peripheral systems, and assembly of compact linear axes using Eline linear sets.
