Standard linear bushing KBM-E-50-D for 50 mm shaft - Bosch Rexroth R061105010
Standard linear bushing KBM-E-50-D by Bosch Rexroth for shafts of 50 mm diameter. Dynamic load capacity 8740 N, static load capacity 8280 N. 1 integrated wiper seal, not lubricated, weight 1.06 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Building a linear guide on hardened precision shafts calls for a bearing with a defined load capacity and low friction. The standard linear bushing KBM-E-50-D runs on shafts of 50 mm diameter and reaches a dynamic load capacity of 8740 N with a static load capacity of 8280 N. Weight: 1.06 kg.
Benefits
- Load capacity: dynamic 8260 N to 8740 N, static 6470 N to 8280 N, depending on load direction relative to the ball rows
- Dynamics: up to 2 m/s, acceleration up to 50 m/s²
- Sealing and lubrication: 1 integrated wiper seal, not lubricated
- Design: E - Adjustable, series Standard (metal)
- Clearance: Radial clearance shaft/bore h6/H7 +60 µm
- Installation dimensions: outer diameter D = 75 mm, length 100 mm
Technical data
| Manufacturer | Bosch Rexroth |
|---|---|
| Manufacturer part number | R061105010 |
| Type designation | KBM-E-50-D |
| Friction coefficient μ | 0.001 ... 0.004 |
| Radial clearance shaft/bore h6/H7 | +60 µm |
| Lubrication | Not lubricated |
| Maximum permissible linear speed vmax | 2 m/s |
| Length of linear bushing | 100 mm |
| Radial clearance shaft h6/bore K7 | +39 µm |
| Series | Standard (metal) |
| Maximum dynamic load capacity Cmax | 8740 N |
| Rows of balls | 6 |
| Breakaway force | 30 N |
| Maximum acceleration rate amax | 50 m/s² |
| Outer diameter D | 75 mm |
| Minimum static load capacity C0min | 6470 N |
| Shaft diameter d | 50 mm |
| Minimum dynamic load capacity Cmin | 8260 N |
| Maximum static load capacity C0max | 8280 N |
| Format of linear bushings | E - Adjustable |
| Version | Normal |
| Friction force FR | 10 N |
| Seal | 1 integrated wiper seal |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Weight | 1.06 kg |
| Manufacturer Nr. | R061105010 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
