Super linear bushing KBA-10-DD for 10 mm shaft - Bosch Rexroth R067021040

Name: Super linear bushing KBA-10-DD for 10 mm shaft - Bosch Rexroth R067021040
Brand: Bosch Rexroth
SKU: BRR-R067021040
Price: 23.72 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Super linear bushing KBA-10-DD by Bosch Rexroth for shafts of 10 mm diameter. Dynamic load capacity 820 N, static load capacity 480 N. 2 integrated wiper seals, not lubricated, weight 0.02 kg.

Net

€23.72

excl. VAT

Item BRR-R067021040

Manufacturer no. R067021040

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Building a linear guide on hardened precision shafts calls for a bearing with a defined load capacity and low friction. The Super linear bushing KBA-10-DD runs on shafts of 10 mm diameter and reaches a dynamic load capacity of 820 N with a static load capacity of 480 N. Weight: 0.02 kg.

Benefits

Load capacity: dynamic 600 N to 820 N, static 330 N to 480 N, depending on load direction relative to the ball rows
Dynamics: up to 3 m/s, acceleration up to 150 m/s²
Sealing and lubrication: 2 integrated wiper seals, not lubricated
Design: Closed, series Super A (with self-alignment feature)
Clearance: Radial clearance shaft/bore h6/H7 +9 µm
Installation dimensions: outer diameter D = 19 mm, length 29 mm

Technical data

Manufacturer	Bosch Rexroth
Manufacturer part number	R067021040
Type designation	KBA-10-DD
Friction coefficient μ	0.001 ... 0.0025
Radial clearance shaft/bore h6/H7	+9 µm
Lubrication	Not lubricated
Maximum permissible linear speed vmax	3 m/s
Length of linear bushing	29 mm
Radial clearance shaft h6/bore K7	+21 µm
Series	Super A (with self-alignment feature)
Maximum dynamic load capacity Cmax	820 N
Rows of balls	5
Breakaway force	1 N
Maximum acceleration rate amax	150 m/s²
Outer diameter D	19 mm
Minimum static load capacity C0min	330 N
Radial clearance shaft h6/bore M7	+15 µm
Shaft diameter d	10 mm
Minimum dynamic load capacity Cmin	600 N
Maximum static load capacity C0max	480 N
Format of linear bushings	Closed
Version	Normal
Friction force FR	0.5 N
Seal	2 integrated wiper seals
Permissible ambient temperature (min. ... max.)	-10 °C ... +80 °C
Weight	0.02 kg
Manufacturer Nr.	R067021040
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
