Super ball bushing KBSH-O-30-VD by Bosch Rexroth, material number R073123045. Seal Fully sealed and lubrication Not lubricated.
Super ball bushing KBSH-O-30-VD - Bosch Rexroth R073123045
BOSCH REXROTH
Original product
Net price (excl. VAT)
€147.15
Item
BRR-R073123045
Manufacturer no.
R073123045
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R073123045
Country of originGermany
ConditionNew
Article
BRR-R073123045
Frequently Bought Together
-
This Item:
€147.15
-
Standard Kb KBM-30 - Bosch Rexroth R060003000
€50.50
-
Super ball bushing KBSH-50-DD - Bosch Rexroth R073025040
€290.71
Total price
Super ball bushing KBSH-O-30-VD by Bosch Rexroth, material number R073123045. Seal Fully sealed and lubrication Not lubricated. The static load capacity is 7180 N. Permissible values are up to 5 m/s travel speed and 150 m/s² acceleration. The weight is 0.25 kg.
Technical data
| Friction coefficient μ | 0.001 ... 0.004 |
|---|---|
| Radial clearance shaft/bore h6/H7 | <prefix>+</prefix>43<suffix></suffix> |
| Lubrication | Not lubricated |
| Maximum permissible linear speed vmax | 5 m/s |
| Length of linear bushing | 68 mm |
| Type | Linear bushing |
| Radial clearance shaft h6/bore K7 | <prefix>+</prefix>25<suffix></suffix> |
| Friction coefficient μ max. | 0.004 |
| Static load capacity C0 | 7180 N |
| Series | Super SH |
| Rows of balls | 10 |
| Breakaway force | 13.5 N |
| Maximum acceleration rate amax | 150 m/s² |
| Outer diameter D | 47 mm |
| Breakaway force footnote 2 | For fully sealed linear bushings |
| Friction force FR footnote 2 | Frictional drags generated by linear bushings with integrate |
| Radial clearance shaft h6/bore M7 | <prefix>+</prefix>18<suffix></suffix> |
| Shaft diameter d | 30 mm |
| Linear guide type | Linear bushing and shaft |
| Format of linear bushings | O - Open |
| Dynamic load capacity C | 6300 N |
| Version | Standard |
| Friction force FR | 6 N |
| Seal | Fully sealed |
| Friction coefficient μ min. | 0.001 |
| Permissible ambient temperature (min) | <prefix>-</prefix>20<suffix></suffix> °C |
| Friction force FR footnote 3 | For fully sealed linear bushings |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.25 kg |
| Permissible ambient temperature (min. ... max.) | -20 °C ... +80 °C |
| Manufacturer Nr. | R073123045 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
