Super linear bushing KBH-O-40-DD for 40 mm shaft - Bosch Rexroth R073324040

Bosch Rexroth ✓ Original product Brand new Made in Germany

Super linear bushing KBH-O-40-DD by Bosch Rexroth for shafts of 40 mm diameter. Dynamic load capacity 9680 N, static load capacity 7600 N. 2 integrated wiper seals, not lubricated, weight 0.36 kg.

Net
€113.89
excl. VAT
Item BRR-R073324040
Manufacturer no. R073324040
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Building a linear guide on hardened precision shafts calls for a bearing with a defined load capacity and low friction. The Super linear bushing KBH-O-40-DD runs on shafts of 40 mm diameter and reaches a dynamic load capacity of 9680 N with a static load capacity of 7600 N. Weight: 0.36 kg.

Benefits

  • Load capacity: dynamic load capacity C = 9680 N, static load capacity C0 = 7600 N
  • Dynamics: up to 5 m/s, acceleration up to 150 m/s²
  • Sealing and lubrication: 2 integrated wiper seals, not lubricated
  • Design: O - Open, series Super H
  • Clearance: Radial clearance shaft h6/bore K7 +29 µm
  • Installation dimensions: outer diameter D = 62 mm, length 80 mm

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR073324040
Type designationKBH-O-40-DD
Friction coefficient μ0.001 ... 0.004
Length of linear bushing80 mm
Radial clearance shaft h6/bore K7+29 µm
Static load capacity C07600 N
SeriesSuper H
Rows of balls6
Breakaway force12 N
Outer diameter D62 mm
Radial clearance shaft h6/bore M7+20 µm
Shaft diameter d40 mm
Format of linear bushingsO - Open
Dynamic load capacity C9680 N
VersionNormal
Friction force FR5 N
Radial clearance shaft/bore h6/H7+50 µm
LubricationNot lubricated
Maximum permissible linear speed vmax5 m/s
Maximum acceleration rate amax150 m/s²
Seal2 integrated wiper seals
Permissible ambient temperature (min. ... max.)-20 °C ... +80 °C
Weight0.36 kg
Manufacturer Nr.R073324040
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
