Super linear bushing KBH-O-50-VD for 50 mm shaft - Bosch Rexroth R073325045

Bosch Rexroth ✓ Original product Brand new Made in Germany

Super linear bushing KBH-O-50-VD by Bosch Rexroth for shafts of 50 mm diameter. Dynamic load capacity 16000 N, static load capacity 12200 N. Fully sealed, not lubricated, weight 0.6 kg.

Net
€188.74
excl. VAT
Item BRR-R073325045
Manufacturer no. R073325045
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Building a linear guide on hardened precision shafts calls for a bearing with a defined load capacity and low friction. The Super linear bushing KBH-O-50-VD runs on shafts of 50 mm diameter and reaches a dynamic load capacity of 16000 N with a static load capacity of 12200 N. Weight: 0.6 kg.

Benefits

  • Load capacity: dynamic load capacity C = 16000 N, static load capacity C0 = 12200 N
  • Dynamics: up to 5 m/s, acceleration up to 150 m/s²
  • Sealing and lubrication: fully sealed, not lubricated
  • Design: O - Open, series Super H
  • Clearance: Radial clearance shaft h6/bore K7 +29 µm
  • Installation dimensions: outer diameter D = 75 mm, length 100 mm

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR073325045
Type designationKBH-O-50-VD
Friction coefficient μ0.001 ... 0.004
Length of linear bushing100 mm
Radial clearance shaft h6/bore K7+29 µm
Static load capacity C012200 N
SeriesSuper H
Rows of balls6
Breakaway force22.5 N
Outer diameter D75 mm
Radial clearance shaft h6/bore M7+20 µm
Shaft diameter d50 mm
Format of linear bushingsO - Open
Dynamic load capacity C16000 N
VersionNormal
Friction force FR9 N
Radial clearance shaft/bore h6/H7+50 µm
LubricationNot lubricated
Maximum permissible linear speed vmax5 m/s
Maximum acceleration rate amax150 m/s²
SealFully sealed
Permissible ambient temperature (min. ... max.)-20 °C ... +80 °C
Weight0.6 kg
Manufacturer Nr.R073325045
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
