Flange linear bushing KBMM-25-DD for 25 mm shaft - Bosch Rexroth R074252500

Bosch Rexroth ✓ Original product Brand new Made in Germany

Flange linear bushing KBMM-25-DD by Bosch Rexroth for shafts of 25 mm diameter. Dynamic load capacity 1350 N, static load capacity 4200 N. 2 integrated wiper seals, not lubricated, weight 0.53 kg.

Net
€197.25
excl. VAT
Item BRR-R074252500
Manufacturer no. R074252500
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Building a linear guide on hardened precision shafts calls for a bearing with a defined load capacity and low friction. The flange linear bushing KBMM-25-DD runs on shafts of 25 mm diameter and reaches a dynamic load capacity of 1350 N with a static load capacity of 4200 N. Weight: 0.53 kg.

Benefits

  • Load capacity: dynamic 1250 N to 1350 N, static 3240 N to 4200 N, depending on load direction relative to the ball rows
  • Dynamics: up to 2.5 m/s, acceleration up to 100 m/s²
  • Sealing and lubrication: 2 integrated wiper seals, not lubricated
  • Design: M - Central flanged, series Standard (metal)
  • Clearance: Shaft radial clearance h6 +22 µm
  • Installation dimensions: outer diameter D = 40 mm, length 112 mm

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR074252500
Type designationKBMM-25-DD
Length of linear bushing112 mm
SeriesStandard (metal)
Shaft radial clearance h6+22 µm
Rows of balls6
Breakaway force14 N
Working bore diameter tolerance+13 µm
Outer diameter D40 mm
Shaft diameter d25 mm
Static longitudinal moment load capacity ML061 Nm
Format of linear bushingsM - Central flanged
VersionNormal
Friction force FR5 N
LubricationNot lubricated
Maximum permissible linear speed vmax2.5 m/s
Maximum dynamic load capacity Cmax1350 N
Maximum acceleration rate amax100 m/s²
Minimum static load capacity C0min3240 N
Minimum dynamic load capacity Cmin1250 N
Maximum static load capacity C0max4200 N
Seal2 integrated wiper seals
Permissible ambient temperature (min. ... max.)-10 °C ... +80 °C
Weight0.53 kg
Manufacturer Nr.R074252500
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
