Linear set LSACE-50-DD-G - Bosch Rexroth R102825044
Linear set LSACE-50-DD-G by Bosch Rexroth, material number R102825044. The static load capacity is 5350 N.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Linear set LSACE-50-DD-G by Bosch Rexroth, material number R102825044. The static load capacity is 5350 N. Permissible values are up to 5 m/s travel speed and 150 m/s² acceleration. The weight is 1.19 kg.
Technical data
| Maximum permissible linear speed vmax | 5 m/s |
|---|---|
| Type | Linear set |
| Static load capacity C0 | 5350 N |
| Series | Compact |
| Breakaway force | 10 N |
| Maximum acceleration rate amax | 150 m/s² |
| Outer diameter D | 62 mm |
| Shaft diameter d | 50 mm |
| Linear guide type | Linear bushing and shaft |
| Format of linear bushings | E - Adjustable |
| Dynamic load capacity C | 7180 N |
| Version | Standard |
| Radial clearance | Clamped to h5 shaft (lower limit) and set to zero-clearance |
| Friction force FR | 4 N |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 1.19 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | R102825044 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
