Ball bushing guides
Linear sets with ball bushings
Bosch Rexroth Eline linear sets with ball bushings (LSAC series) combine a ball bushing and housing into a ready-to-install unit. The sets are available in shaft diameters of 12, 16, and 20 mm, each in versions -DD-RT-G (open both sides, with retaining clip and seal) and -DD-RT-NR-G (open both sides, without retaining clip, with seal). The suffix -G indicates a grease nipple fitting, which allows relubrication without dismounting.
- 607 items
- 1 manufacturer
- Net prices plus VAT
Buying guide
How to choose Linear sets with ball bushings
What matters when choosing: properties, comparison and typical applications.
Technical features
LSAC delivery programme
| Type | Article no. | Shaft diameter |
|---|---|---|
| LSAC-12-DD-RT-G | R102725144 | 12 mm |
| LSAC-12-DD-RT-NR-G | R102725134 | 12 mm, without retaining clip |
| LSAC-16-DD-RT-G | R102725244 | 16 mm |
| LSAC-16-DD-RT-NR-G | R102725234 | 16 mm, without retaining clip |
| LSAC-20-DD-RT-G | R102725344 | 20 mm |
Typical applications
Typical applications: Ready-to-install linear carriage guides in handling modules and feed automation systems, low-maintenance linear guides in food and packaging machinery with grease nipple, carriage guides in printing systems and laboratory automation, retrofitting simple linear guides with a complete housing system, and new designs requiring compact installation dimensions and minimal assembly effort.
