Linear set LSACT-12-DD-NR-G - Bosch Rexroth R102921234
Linear set LSACT-12-DD-NR-G by Bosch Rexroth, material number R102921234. The static load capacity is 780 N.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Linear set LSACT-12-DD-NR-G by Bosch Rexroth, material number R102921234. The static load capacity is 780 N. Permissible values are up to 5 m/s travel speed and 150 m/s² acceleration. The weight is 0.17 kg.
Technical data
| Maximum permissible linear speed vmax | 5 m/s |
|---|---|
| Type | Linear set |
| Static load capacity C0 | 780 N |
| Series | Compact |
| Shaft radial clearance h6 | <prefix>+</prefix>32<suffix></suffix> |
| Breakaway force | 1.5 N |
| Maximum acceleration rate amax | 150 m/s² |
| Outer diameter D | 19 mm |
| Shaft diameter d | 12 mm |
| Static longitudinal moment load capacity ML0 | 13 Nm |
| Linear guide type | Linear bushing and shaft |
| Format of linear bushings | – Closed |
| Dynamic load capacity C | 920 N |
| Version | Corrosion-resistant |
| Friction force FR | 0.8 N |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.17 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | R102921234 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
