Linear set LSAOE-B-12-DD by Bosch Rexroth, material number R103881220. The static load capacity is 510 N.
Linear set LSAOE-B-12-DD - Bosch Rexroth R103881220
BOSCH REXROTH
Original product
Net price (excl. VAT)
€53.58
Item
BRR-R103881220
Manufacturer no.
R103881220
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R103881220
Country of originGermany
ConditionNew
Article
BRR-R103881220
Frequently Bought Together
-
This Item:
€53.58
-
Linear set LSGOE-M-80-DD - Bosch Rexroth R106828000
€488.53
-
Linear set LSK-40-DD - Bosch Rexroth R106024000
€50.28
Total price
Linear set LSAOE-B-12-DD by Bosch Rexroth, material number R103881220. The static load capacity is 510 N. Permissible values are up to 3 m/s travel speed and 150 m/s² acceleration. The weight is 0.11 kg.
Technical data
| Maximum permissible linear speed vmax | 3 m/s |
|---|---|
| Type | Linear set |
| Static load capacity C0 | 510 N |
| Series | Super B (no self-alignment feature) |
| Breakaway force | 1.5 N |
| Maximum acceleration rate amax | 150 m/s² |
| Outer diameter D | 22 mm |
| Shaft diameter d | 12 mm |
| Linear guide type | Linear bushing and shaft |
| Format of linear bushings | OE - Open, adjustable |
| Dynamic load capacity C | 1060 N |
| Radial clearance | Clamped to h5 shaft (lower limit) and set to zero-clearance |
| Friction force FR | 0.8 N |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.11 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer Nr. | R103881220 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
