Linear set (plastic) LSK-20-DD-NR for 20 mm shaft - Bosch Rexroth R106022020

Name: Linear set (plastic) LSK-20-DD-NR for 20 mm shaft - Bosch Rexroth R106022020
Brand: Bosch Rexroth
SKU: BRR-R106022020
Price: 35.29 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (plastic) LSK-20-DD-NR by Bosch Rexroth for shafts of 20 mm diameter. Dynamic load capacity 510 N, static load capacity 690 N. Weight 0.08 kg, material number R106022020.

Net

€35.29

excl. VAT

Item BRR-R106022020

Manufacturer no. R106022020

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSK-20-DD-NR is designed for shafts of 20 mm diameter and carries 510 N dynamic and 690 N static load. Weight: 0.08 kg.

Benefits

Load capacity: dynamic load capacity C = 510 N, static load capacity C0 = 690 N
Dynamics: up to 3 m/s, acceleration up to 150 m/s²
Design: Closed
Clearance: Radial clearance set to zero clearance on an h5 shaft (lower limit) at the factory
Material: Corrosion-resistant
Temperature range: -10 °C ... +65 °C

Technical data

Manufacturer	Bosch Rexroth
Manufacturer part number	R106022020
Type designation	LSK-20-DD-NR
Maximum permissible linear speed vmax	3 m/s
Static load capacity C0	690 N
Breakaway force	5 N
Maximum acceleration rate amax	150 m/s²
Shaft diameter d	20 mm
Format of linear bushings	Closed
Dynamic load capacity C	510 N
Version	Corrosion-resistant
Radial clearance	set to zero clearance on an h5 shaft (lower limit) at the factory
Friction force FR	2.5 N
Permissible ambient temperature (min. ... max.)	-10 °C ... +65 °C
Weight	0.08 kg
Manufacturer Nr.	R106022020
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
