Linear set (steel) LSGE-A-16-DD for 16 mm shaft - Bosch Rexroth R106661640

Name: Linear set (steel) LSGE-A-16-DD for 16 mm shaft - Bosch Rexroth R106661640
Brand: Bosch Rexroth
SKU: BRR-R106661640
Price: 41.65 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (steel) LSGE-A-16-DD by Bosch Rexroth for shafts of 16 mm diameter. Dynamic load capacity 1500 N, static load capacity 830 N. Weight 0.24 kg, material number R106661640.

Net

€41.65

excl. VAT

Item BRR-R106661640

Manufacturer no. R106661640

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSGE-A-16-DD is designed for shafts of 16 mm diameter and carries 1500 N dynamic and 830 N static load. Weight: 0.24 kg.

Benefits

Load capacity: dynamic load capacity C = 1500 N, static load capacity C0 = 830 N
Dynamics: up to 3 m/s, acceleration up to 150 m/s²
Design: E - Adjustable, series Super A (with self-alignment feature)
Clearance: Radial clearance set to zero clearance on an h5 shaft (lower limit) at the factory
Installation dimensions: outer diameter D = 26 mm
Temperature range: -10 °C ... +80 °C

Technical data

Manufacturer	Bosch Rexroth
Manufacturer part number	R106661640
Type designation	LSGE-A-16-DD
Maximum permissible linear speed vmax	3 m/s
Static load capacity C0	830 N
Series	Super A (with self-alignment feature)
Breakaway force	2 N
Maximum acceleration rate amax	150 m/s²
Outer diameter D	26 mm
Shaft diameter d	16 mm
Format of linear bushings	E - Adjustable
Dynamic load capacity C	1500 N
Radial clearance	set to zero clearance on an h5 shaft (lower limit) at the factory
Dimension B1	22 mm
Friction force FR	1 N
Permissible ambient temperature (min. ... max.)	-10 °C ... +80 °C
Weight	0.24 kg
Manufacturer Nr.	R106661640
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
