Linear set (aluminum) LSADR1-40-WV-600 for 40 mm shaft - Bosch Rexroth R109824080

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Linear set (aluminum) LSADR1-40-WV-600 for 40 mm shaft - Bosch Rexroth R109824080

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (aluminum) LSADR1-40-WV-600 by Bosch Rexroth for shafts of 40 mm diameter. Dynamic load capacity 6320 N, static load capacity 4350 N, torque up to 53 Nm. Weight 0.45 kg, material number R109824080.

Net
€471.54
excl. VAT
Item BRR-R109824080
Manufacturer no. R109824080
Save Compare
Question about this item
Datasheet (PDF) User manual 5 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSADR1-40-WV-600 is designed for shafts of 40 mm diameter and carries 6320 N dynamic and 4350 N static load. Weight: 0.45 kg.

Benefits

  • Load capacity: dynamic load capacity C = 6320 N, static load capacity C0 = 4350 N
  • Torque transmission: dynamic torsional moment load capacity Mt = 53 Nm
  • Dynamics: up to 3 m/s, acceleration up to 150 m/s²
  • Design: series Torque
  • Installation dimensions: outer diameter D = 62 mm
  • Temperature range: -10 °C ... +80 °C

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR109824080
Type designationLSADR1-40-WV-600
Maximum permissible linear speed vmax3 m/s
Mass m (kg/m)9.8 kg/m
Dynamic torsional moment load capacity Mt53 Nm
Static load capacity C04350 N
SeriesTorque
Maximum acceleration rate amax150 m/s²
Outer diameter D62 mm
Shaft diameter d40 mm
Dynamic load capacity C6320 N
Permissible ambient temperature (min. ... max.)-10 °C ... +80 °C
Weight0.45 kg
Manufacturer Nr.R109824080
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
