Linear set (steel) KB-RCS-E-40-VD for 40 mm shaft - Bosch Rexroth R161340000
Linear set (steel) KB-RCS-E-40-VD by Bosch Rexroth for shafts of 40 mm diameter. Dynamic load capacity 13900 N, static load capacity 16000 N. Weight 3.71 kg, material number R161340000.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set KB-RCS-E-40-VD is designed for shafts of 40 mm diameter and carries 13900 N dynamic and 16000 N static load. Weight: 3.71 kg.
Benefits
- Load capacity: dynamic load capacity C = 13900 N, static load capacity C0 = 16000 N
- Dynamics: up to 2 m/s, acceleration up to 50 m/s²
- Design: OE - Open, adjustable, series Radial compact set
- Clearance: Radial clearance set to zero clearance on an h5 shaft (lower limit) at the factory
- Temperature range: -20 °C ... +100 °C
Technical data
| Manufacturer | Bosch Rexroth |
|---|---|
| Manufacturer part number | R161340000 |
| Type designation | KB-RCS-E-40-VD |
| Friction coefficient μ | 0.001 ... 0.002 |
| Static load capacity C0 | 16000 N |
| Series | Radial compact set |
| Breakaway force | 32 N |
| Shaft diameter d | 40 mm |
| Format of linear bushings | OE - Open, adjustable |
| Dynamic load capacity C | 13900 N |
| Friction force FR | 16 N |
| Maximum permissible linear speed vmax | 2 m/s |
| Maximum acceleration rate amax | 50 m/s² |
| Radial clearance | set to zero clearance on an h5 shaft (lower limit) at the factory |
| Permissible ambient temperature (min. ... max.) | -20 °C ... +100 °C |
| Weight | 3.71 kg |
| Manufacturer Nr. | R161340000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
