Linear set (steel) KB-RCS-E-50-VD for 50 mm shaft - Bosch Rexroth R161350000

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (steel) KB-RCS-E-50-VD by Bosch Rexroth for shafts of 50 mm diameter. Dynamic load capacity 20800 N, static load capacity 24400 N. Weight 7.57 kg, material number R161350000.

Net
€1,332.77
excl. VAT
Item BRR-R161350000
Manufacturer no. R161350000
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set KB-RCS-E-50-VD is designed for shafts of 50 mm diameter and carries 20800 N dynamic and 24400 N static load. Weight: 7.57 kg.

Benefits

  • Load capacity: dynamic load capacity C = 20800 N, static load capacity C0 = 24400 N
  • Dynamics: up to 2 m/s, acceleration up to 50 m/s²
  • Design: OE - Open, adjustable, series Radial compact set
  • Clearance: Radial clearance set to zero clearance on an h5 shaft (lower limit) at the factory
  • Temperature range: -20 °C ... +100 °C

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR161350000
Type designationKB-RCS-E-50-VD
Friction coefficient μ0.001 ... 0.002
Static load capacity C024400 N
SeriesRadial compact set
Breakaway force40 N
Shaft diameter d50 mm
Format of linear bushingsOE - Open, adjustable
Dynamic load capacity C20800 N
Friction force FR20 N
Maximum permissible linear speed vmax2 m/s
Maximum acceleration rate amax50 m/s²
Radial clearanceset to zero clearance on an h5 shaft (lower limit) at the factory
Permissible ambient temperature (min. ... max.)-20 °C ... +100 °C
Weight7.57 kg
Manufacturer Nr.R161350000
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
