Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
Kugelwagen HS KWC-055-SNS-C2-H-2 by Bosch Rexroth, material number R162252390. Size 55, material Carbon steel, accuracy class H - Highly accurate, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved.
Bosch Rexroth R162252390. Kugelwagen HS KWC-055-SNS-C2-H-2
BOSCH REXROTH
Original product
Net price (excl. VAT)
€1,362.00
Item
BRR-R162252390
Manufacturer no.
R162252390
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R162252390
Country of originGermany
ConditionNew
Article
BRR-R162252390
Frequently Bought Together
-
This Item:
€1,362.00
-
Ball runner block KWD-025-SKS-C1-H-1 - Bosch Rexroth R166221321
€71.69
-
Ball runner block KWD-020-FKS-C0-H-0 - Bosch Rexroth R200089304
€118.91
Total price
Kugelwagen HS KWC-055-SNS-C2-H-2 by Bosch Rexroth, material number R162252390. Size 55, material Carbon steel, accuracy class H - Highly accurate, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved. The dynamic load capacity is 76300 N. The static load capacity is 122000 N. Permissible values are up to 7.5 m/s travel speed and 250 m/s² acceleration. The weight is 3.55 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 70 mm |
| Ball chain | Without ball chain (standard) |
| Lubrication | Preserved |
| Maximum permissible linear speed vmax | 7.5 m/s |
| Friction coefficient μ max. | 0.003 |
| Nominal size | 55 |
| Preload class | C2 - Medium preload |
| Static load capacity C0 | 122000 N |
| Dynamic load capacity C50 | 96100 N |
| Material (profiled rail systems) | Carbon steel |
| Dimension T | 120 mm |
| Height of runner block | 57 mm |
| Format | SNS - slimline, normal, standard height |
| Self-aligning for compensation of misalignments | Without self-alignment |
| Maximum acceleration rate amax | 250 m/s² |
| Dynamic load capacity C100 | 76300 N |
| Dynamic longitudinal moment load capacity ML50 | 2040 Nm |
| Dynamic longitudinal moment load capacity ML100 | 1620 Nm |
| Dynamic torsional moment load capacity Mt50 | 3050 Nm |
| Length of runner block | 159 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 100 mm |
| Static torsional moment load capacity Mt0 | 3880 Nm |
| Dynamic torsional moment load capacity Mt100 | 2420 Nm |
| Static longitudinal moment load capacity ML0 | 2580 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | H - Highly accurate |
| Dimension B1 | 115.5 mm |
| Seal | SS - Standard seal |
| Friction coefficient μ min. | 0.002 |
| Model | High-speed ball runner block |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 3.55 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Norm | DIN ISO 14728-1 |
|---|---|
| Manufacturer Nr. | R162252390 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Preload | C2 |
| Accuracy class | H - High |
| Position sensing | No |
