High-precision runner blocks of the Bosch Rexroth BSHP series form the moving element of the ball rail guidance system. Four rows of balls in an O-arrangement absorb forces and moments evenly in all four main directions - delivering high rigidity, smooth travel and a constant drive force over the entire service life. Load and moment ratings are defined according to ISO 14728-1.
esd.equipment supplies the BSHP runner block range in sizes 15 to 65, in flanged (FNS) and narrow versions, with steel or aluminium bodies. Preload classes C0/C1/C2 and accuracy classes H, P, SP and UP are selectable - all mounting dimensions follow DIN 645, so blocks combine freely with the BSHP ball rails.
BSHP runner blocks - overview by size
| Size | Version | Preload | Accuracy |
|---|---|---|---|
| 15 / 20 | Flanged FNS, narrow SNS | C0 / C1 | H / P / SP |
| 25 / 30 | Flanged FNS, high version | C0 / C1 / C2 | H / P / SP / UP |
| 35 / 45 | Flanged FNS | C1 / C2 | H / P / SP |
| 55 / 65 | Flanged FNS, heavy duty | C1 / C2 | H / P |
Typical applications: Machine tools and machining centres, handling and automation technology, measuring and test machines, semiconductor and electronics manufacturing, packaging and printing machinery, and special-purpose machine building with high demands on precision and rigidity.
