Bosch Rexroth
Ball runner block KWD-025-SLH-C2-X-1 - Bosch Rexroth R162422822
Item BRR-R162422822
€147.61
Images are examples, some edited with AI. The technical data are authoritative. AI notice
Bosch Rexroth R162352290. Kugelwagen HS KWC-055-SLS-C2-P-2
Kugelwagen HS KWC-055-SLS-C2-P-2 by Bosch Rexroth, material number R162352290. Size 55 mm, material Carbon steel, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Kugelwagen HS KWC-055-SLS-C2-P-2 by Bosch Rexroth, material number R162352290. Size 55 mm, material Carbon steel, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved. The dynamic load capacity is 96700 N. The static load capacity is 171000 N. Permissible values are up to 7.5 m/s travel speed and 250 m/s² acceleration. The weight is 4.5 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 70 mm |
| Ball chain | Without ball chain (standard) |
| Lubrication | Preserved |
| Maximum permissible linear speed vmax | 7.5 m/s |
| Friction coefficient μ max. | 0.003 |
| Nominal size | 55 mm |
| Preload class | C2 - Medium preload |
| Static load capacity C0 | 171000 N |
| Dynamic load capacity C50 | 122000 N |
| Material (profiled rail systems) | Carbon steel |
| Dimension T | 120 mm |
| Height of runner block | 57 mm |
| Format | SLS - slimline, long, standard height |
| Self-aligning for compensation of misalignments | Without self-alignment |
| Maximum acceleration rate amax | 250 m/s² |
| Dynamic load capacity C100 | 96700 N |
| Dynamic longitudinal moment load capacity ML50 | 3490 Nm |
| Dynamic longitudinal moment load capacity ML100 | 2770 Nm |
| Dynamic torsional moment load capacity Mt50 | 3870 Nm |
| Length of runner block | 199 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 100 mm |
| Static torsional moment load capacity Mt0 | 5420 Nm |
| Dynamic torsional moment load capacity Mt100 | 3070 Nm |
| Static longitudinal moment load capacity ML0 | 4880 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | P - Precise |
| Dimension B1 | 155.5 mm |
| Seal | SS - Standard seal |
| Friction coefficient μ min. | 0.002 |
| Model | High-speed ball runner block |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 4.5 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | R162352290 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN ISO 14728-1 |
| Preload | C2 |
Downloads
Datasheet
- Datasheet (PDF)
- Ball rail systems High Precision BSHP Ball runner blocks, ball guide rails, accessories (R999000485) EN
- Kugelschienenführungen Hochpräzision BSHP Kugelwagen, Kugelschienen, Zubehör Inhaltsverzeichnis DE
- Guidages à billes sur rails de haute précision BSHP Guides à billes, rails à billes, accessoires FR
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day. Ask a question
