Kugelwagen CS KWC-065-FNS-C2-U-2 by Bosch Rexroth, material number R165162910. Size 65, material Carbon steel, accuracy class UP - Ultra precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved.
Bosch Rexroth R165162910. Kugelwagen CS KWC-065-FNS-C2-U-2
BOSCH REXROTH
Original product
Net price (excl. VAT)
€560.97
Item
BRR-R165162910
Manufacturer no.
R165162910
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R165162910
Country of originGermany
ConditionNew
Article
BRR-R165162910
Frequently Bought Together
-
This Item:
€560.97
-
Ball runner block KWD-015-FLS-C1-X-1 - Bosch Rexroth R165311820
€112.76
-
Ball runner block AL KWD-035-FNS-C0-N-1 - Bosch Rexroth R163139423
€112.71
Total price
Kugelwagen CS KWC-065-FNS-C2-U-2 by Bosch Rexroth, material number R165162910. Size 65, material Carbon steel, accuracy class UP - Ultra precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved. The dynamic load capacity is 172000 N. The static load capacity is 280000 N. Permissible values are up to 3 m/s travel speed and 250 m/s² acceleration. The weight is 10.25 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 90 mm |
| Pitch T guide rail | 150 mm |
| Ball chain | Without ball chain (standard) |
| Nominal size | 65 |
| Preload class | C2 - Medium preload |
| Static load capacity C0 | 280000 N |
| Height of runner block | 76 mm |
| Format | FNS - flange, normal, standard height |
| Self-aligning for compensation of misalignments | Without self-alignment |
| Length of runner block | 188 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 170 mm |
| Static torsional moment load capacity Mt0 | 11100 Nm |
| Dynamic torsional moment load capacity Mt100 | 6810 Nm |
| Static longitudinal moment load capacity ML0 | 7400 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | UP - Ultra precise |
| Dimension B1 | 139.6 mm |
| Friction coefficient μ min. | 0.002 |
| Model | Heavy-duty ball runner block |
| Lubrication | Preserved |
| Maximum permissible linear speed vmax | 3 m/s |
| Friction coefficient μ max. | 0.003 |
| Dynamic load capacity C50 | 217000 N |
| Material (profiled rail systems) | Carbon steel |
| Preload force | 9840 N |
| Maximum acceleration rate amax | 250 m/s² |
| Dynamic load capacity C100 | 172000 N |
| Dynamic longitudinal moment load capacity ML50 | 5750 Nm |
| Dynamic longitudinal moment load capacity ML100 | 4560 Nm |
| Dynamic torsional moment load capacity Mt50 | 8580 Nm |
| Dimension T1 min | 21 mm |
| Seal | SS - Standard seal |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 10.25 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Norm | DIN ISO 14728-1 |
|---|---|
| Manufacturer Nr. | R165162910 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Preload | C2 |
| Accuracy class | U - Ultra-precision |
| Position sensing | No |
