Ball runner block KWD-045-FLS-C1-N-1 by Bosch Rexroth, material number R165341422. Size 45, material Carbon steel, accuracy class N - Normal, preload class C1 - Low preload, seal SS - Standard seal and lubrication Pre-lubricated, preserved.
Ball runner block KWD-045-FLS-C1-N-1 - Bosch Rexroth R165341422
BOSCH REXROTH
Original product
Net price (excl. VAT)
€162.20
Item
BRR-R165341422
Manufacturer no.
R165341422
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R165341422
Country of originGermany
ConditionNew
Article
BRR-R165341422
Frequently Bought Together
-
This Item:
€162.20
-
Bosch Rexroth R200281404. Kugelwagen NRII KWD-020-FLS-C1-N-0
€162.78
-
Ball runner block AL KWD-030-SNS-C0-H-1 - Bosch Rexroth R163279322
€104.33
Total price
Ball runner block KWD-045-FLS-C1-N-1 by Bosch Rexroth, material number R165341422. Size 45, material Carbon steel, accuracy class N - Normal, preload class C1 - Low preload, seal SS - Standard seal and lubrication Pre-lubricated, preserved. The dynamic load capacity is 106000 N. The static load capacity is 177000 N. Permissible values are up to 5 m/s travel speed and 500 m/s² acceleration. The weight is 4.3 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 60 mm |
| Pitch T guide rail | 105 mm |
| Ball chain | With ball chain |
| Nominal size | 45 |
| Preload class | C1 - Low preload |
| Static load capacity C0 | 177000 N |
| Height of runner block | 50.3 mm |
| Format | FLS - flange, long, standard height |
| Self-aligning for compensation of misalignments | Without self-alignment |
| Length of runner block | 174.1 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 120 mm |
| Static torsional moment load capacity Mt0 | 4770 Nm |
| Dynamic torsional moment load capacity Mt100 | 2870 Nm |
| Static longitudinal moment load capacity ML0 | 4370 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | N - Normal |
| Dimension B1 | 133.5 mm |
| Friction coefficient μ min. | 0.002 |
| Model | High-precision ball runner block |
| Lubrication | Pre-lubricated, preserved |
| Maximum permissible linear speed vmax | 5 m/s |
| Friction coefficient μ max. | 0.003 |
| Dynamic load capacity C50 | 134000 N |
| Material (profiled rail systems) | Carbon steel |
| Preload force | 1640 N |
| Maximum acceleration rate amax | 500 m/s² |
| Dynamic load capacity C100 | 106000 N |
| Dynamic longitudinal moment load capacity ML50 | 3310 Nm |
| Dynamic longitudinal moment load capacity ML100 | 2630 Nm |
| Dynamic torsional moment load capacity Mt50 | 3620 Nm |
| Dimension T1 min | 18 mm |
| Seal | SS - Standard seal |
| Permissible ambient temperature (min) | <prefix></prefix>0<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 4.3 kg |
| Permissible ambient temperature (min. ... max.) | 0 °C ... +80 °C |
| Manufacturer Nr. | R165341422 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
