Ball runner block KWD-025-FKS-C0-N-1 by Bosch Rexroth, material number R166129420. Size 25, material Carbon steel, accuracy class N - Normal, preload class C0 - Without preload (clearance), seal SS - Standard seal and lubrication Pre-lubricated, preserved.
Ball runner block KWD-025-FKS-C0-N-1 - Bosch Rexroth R166129420
BOSCH REXROTH
Original product
Net price (excl. VAT)
€71.87
Item
BRR-R166129420
Manufacturer no.
R166129420
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R166129420
Country of originGermany
ConditionNew
Article
BRR-R166129420
Frequently Bought Together
-
This Item:
€71.87
-
Bosch Rexroth R165152310. Kugelwagen CS KWC-055-FNS-C2-H-2
€189.57
-
Ball runner block AL KWD-015-FNS-C0-N-1 - Bosch Rexroth R163119422
€70.77
Total price
Ball runner block KWD-025-FKS-C0-N-1 by Bosch Rexroth, material number R166129420. Size 25, material Carbon steel, accuracy class N - Normal, preload class C0 - Without preload (clearance), seal SS - Standard seal and lubrication Pre-lubricated, preserved. The dynamic load capacity is 11400 N. Permissible values are up to 5 m/s travel speed and 500 m/s² acceleration. The weight is 0.5 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 36 mm |
| Pitch T guide rail | 60 mm |
| Ball chain | Without ball chain (standard) |
| Nominal size | 25 |
| Preload class | C0 - Without preload (clearance) |
| Maximum permissible torsional moment Mt max | 65 Nm |
| Height of runner block | 29.9 mm |
| Maximum dynamic load Fmax | 4400 N |
| Format | FKS - flange, short, standard height |
| Self-aligning for compensation of misalignments | With self-alignment |
| Length of runner block | 67 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 70 mm |
| Dynamic torsional moment load capacity Mt100 | 170 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | N - Normal |
| Dimension B1 | 38.6 mm |
| Friction coefficient μ min. | 0.002 |
| Model | Super ball runner block |
| Lubrication | Pre-lubricated, preserved |
| Maximum permissible linear speed vmax | 5 m/s |
| Friction coefficient μ max. | 0.003 |
| Dynamic load capacity C50 | 14400 N |
| Material (profiled rail systems) | Carbon steel |
| Maximum acceleration rate amax | 500 m/s² |
| Dynamic load capacity C100 | 11400 N |
| Dynamic torsional moment load capacity Mt50 | 210 Nm |
| Dimension T1 min | 13 mm |
| Seal | SS - Standard seal |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.5 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer Nr. | R166129420 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
