Ball runner block KWD-020-BNS-C0-N-1 by Bosch Rexroth, material number R167159420. Size 20/40, material Carbon steel, accuracy class N - Normal, preload class C0 - Without preload (clearance), seal SS - Standard seal and lubrication Pre-lubricated, preserved.
Ball runner block KWD-020-BNS-C0-N-1 - Bosch Rexroth R167159420
BOSCH REXROTH
Original product
Net price (excl. VAT)
€136.32
Item
BRR-R167159420
Manufacturer no.
R167159420
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R167159420
Country of originGermany
ConditionNew
Article
BRR-R167159420
Frequently Bought Together
-
This Item:
€136.32
-
Ball runner block KWD-035-FNS-C0-N-0 - Bosch Rexroth R200139407
€198.56
-
Ball runner block KWD-025-SNH-C0-N-1 - Bosch Rexroth R162129420
€85.36
Total price
Ball runner block KWD-020-BNS-C0-N-1 by Bosch Rexroth, material number R167159420. Size 20/40, material Carbon steel, accuracy class N - Normal, preload class C0 - Without preload (clearance), seal SS - Standard seal and lubrication Pre-lubricated, preserved. The dynamic load capacity is 14900 N. The static load capacity is 20600 N. Permissible values are up to 5 m/s travel speed and 500 m/s² acceleration. The weight is 0.4 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 27 mm |
| Pitch T guide rail | 60 mm |
| Ball chain | Without ball chain (standard) |
| Nominal size | 20/40 |
| Size footnote | Attention: Ball runner blocks, not combinable with ball guid |
| Preload class | C0 - Without preload (clearance) |
| Static load capacity C0 | 20600 N |
| Height of runner block | 22.5 mm |
| Format | BNS - wide, normal, standard height |
| Self-aligning for compensation of misalignments | Without self-alignment |
| Length of runner block | 73 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 80 mm |
| Static torsional moment load capacity Mt0 | 470 Nm |
| Dynamic torsional moment load capacity Mt100 | 340 Nm |
| Static longitudinal moment load capacity ML0 | 190 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | N - Normal |
| Dimension B1 | 51.3 mm |
| Friction coefficient μ min. | 0.002 |
| Model | Wide ball runner block |
| Lubrication | Pre-lubricated, preserved |
| Maximum permissible linear speed vmax | 5 m/s |
| Friction coefficient μ max. | 0.003 |
| Dynamic load capacity C50 | 18800 N |
| Material (profiled rail systems) | Carbon steel |
| Maximum acceleration rate amax | 500 m/s² |
| Dynamic load capacity C100 | 14900 N |
| Dynamic longitudinal moment load capacity ML50 | 180 Nm |
| Dynamic longitudinal moment load capacity ML100 | 140 Nm |
| Dynamic torsional moment load capacity Mt50 | 430 Nm |
| Dimension T1 min | 10 mm |
| Seal | SS - Standard seal |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.4 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer Nr. | R167159420 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
