Rollenwagen CS RWA-065-FXS-C2-U-2 by Bosch Rexroth, material number R185462910. Size 65, material Carbon steel, accuracy class UP - Ultra precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved.
Bosch Rexroth R185462910. Rollenwagen CS RWA-065-FXS-C2-U-2
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,150.40
Item
BRR-R185462910
Manufacturer no.
R185462910
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R185462910
Country of originGermany
ConditionNew
Article
BRR-R185462910
Frequently Bought Together
-
This Item:
€2,150.40
-
Front seal 55 SET - Bosch Rexroth R181051000
€14.28
-
Roller runner block RWD-055-SLS-C2-S-2-AS - Bosch Rexroth R18235212A
€864.83
Total price
Rollenwagen CS RWA-065-FXS-C2-U-2 by Bosch Rexroth, material number R185462910. Size 65, material Carbon steel, accuracy class UP - Ultra precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved. The dynamic load capacity is 366800 N. The static load capacity is 792800 N. Permissible values are up to 3 m/s travel speed and 150 m/s² acceleration. The weight is 20.3 kg.
Technical data
| Friction coefficient μ | 0.0004 ... 0.001 |
|---|---|
| Height runner block with guide rail | 90 mm |
| Pitch T guide rail | 75 mm |
| Nominal size | 65 |
| Preload class | C2 - Medium preload |
| Static load capacity C0 | 792800 N |
| Height of runner block | 76 mm |
| Format | FXS - flange, extra long, standard height |
| Length of runner block | 335 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 170 mm |
| Static torsional moment load capacity Mt0 | 28170 Nm |
| Dynamic torsional moment load capacity Mt100 | 13030 Nm |
| Static longitudinal moment load capacity ML0 | 34060 Nm |
| Linear guide type | Roller rail system |
| Version | Roller rail systems |
| Accuracy class | UP - Ultra precise |
| Dimension B1 | 275 mm |
| Friction force FR | 90 N |
| Friction coefficient μ min. | 0.0004 |
| Model | Heavy-duty roller runner block |
| Lubrication | Preserved |
| Maximum permissible linear speed vmax | 3 m/s |
| Friction coefficient μ max. | 0.001 |
| Dynamic load capacity C50 | 451000 N |
| Material (profiled rail systems) | Carbon steel |
| Preload force | 29300 N |
| Maximum acceleration rate amax | 150 m/s² |
| Dynamic load capacity C100 | 366800 N |
| Dynamic longitudinal moment load capacity ML50 | 19400 Nm |
| Dynamic longitudinal moment load capacity ML100 | 15760 Nm |
| Dynamic torsional moment load capacity Mt50 | 16000 Nm |
| Dimension T1 min | 21 mm |
| Seal | SS - Standard seal |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 20.3 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Norm | DIN ISO 14728-1 |
|---|---|
| Manufacturer Nr. | R185462910 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Preload | C2 |
| Accuracy class | U - Ultra-precision |
| Position sensing | No |
