Kugelwagen HS KWD-045-FNS-C2-P-1 by Bosch Rexroth, material number R200142290. Size 45 mm, material Carbon steel, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Pre-lubricated, preserved.
Bosch Rexroth R200142290. Kugelwagen HS KWD-045-FNS-C2-P-1
BOSCH REXROTH
Original product
Net price (excl. VAT)
€1,177.67
Item
BRR-R200142290
Manufacturer no.
R200142290
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R200142290
Country of originGermany
ConditionNew
Article
BRR-R200142290
Frequently Bought Together
-
This Item:
€1,177.67
-
Ball runner block KWD-020-FLS-C1-N-0 - Bosch Rexroth R200281405
€162.78
-
Ball runner block KWD-015-FNS-C3-X-1 - Bosch Rexroth R165113822
€101.42
Total price
Kugelwagen HS KWD-045-FNS-C2-P-1 by Bosch Rexroth, material number R200142290. Size 45 mm, material Carbon steel, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Pre-lubricated, preserved. The dynamic load capacity is 60300 N. The static load capacity is 92100 N. Permissible values are up to 10 m/s travel speed and 500 m/s² acceleration. The weight is 2.85 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 60 mm |
| Pitch T guide rail | 105 mm |
| Ball chain | Without ball chain (standard) |
| Lubrication | Pre-lubricated, preserved |
| Maximum permissible linear speed vmax | 10 m/s |
| Friction coefficient μ max. | 0.003 |
| Nominal size | 45 mm |
| Preload class | C2 - Medium preload |
| Static load capacity C0 | 92100 N |
| Dynamic load capacity C50 | 76000 N |
| Material (profiled rail systems) | Carbon steel |
| Dimension T | 105 mm |
| Height of runner block | 50.3 mm |
| Format | FNS - flange, normal, standard height |
| Self-aligning for compensation of misalignments | Without self-alignment |
| Maximum acceleration rate amax | 500 m/s² |
| Dynamic load capacity C100 | 60300 N |
| Dynamic longitudinal moment load capacity ML50 | 1350 Nm |
| Dynamic longitudinal moment load capacity ML100 | 1070 Nm |
| Dynamic torsional moment load capacity Mt50 | 2050 Nm |
| Length of runner block | 137.5 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 120 mm |
| Static torsional moment load capacity Mt0 | 2490 Nm |
| Dynamic torsional moment load capacity Mt100 | 1630 Nm |
| Static longitudinal moment load capacity ML0 | 1640 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | P - Precise |
| Dimension B1 | 97 mm |
| Seal | SS - Standard seal |
| Friction coefficient μ min. | 0.002 |
| Model | High-speed ball runner block |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 2.85 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Norm | DIN ISO 14728-1 |
|---|---|
| Manufacturer Nr. | R200142290 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Preload | C2 |
| Accuracy class | P - Precision |
| Position sensing | No |
