Bosch Rexroth R200232290. Kugelwagen HS KWD-035-FLS-C2-P-1

Name: Bosch Rexroth R200232290. Kugelwagen HS KWD-035-FLS-C2-P-1
Brand: Bosch Rexroth
SKU: BRR-R200232290
Price: 596.22 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Net

€596.22

excl. VAT

Item BRR-R200232290

Manufacturer no. R200232290

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Kugelwagen HS KWD-035-FLS-C2-P-1 by Bosch Rexroth, material number R200232290. Size 35, material Carbon steel, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Pre-lubricated, preserved. The dynamic load capacity is 46600 N. The static load capacity is 81100 N. Permissible values are up to 10 m/s travel speed and 500 m/s² acceleration. The weight is 2.25 kg.

Technical data

Friction coefficient μ	0.002 ... 0.003
Height runner block with guide rail	48 mm
Pitch T guide rail	80 mm
Ball chain	Without ball chain (standard)
Nominal size	35
Preload class	C2 - Medium preload
Static load capacity C0	81100 N
Height of runner block	40.4 mm
Format	FLS - flange, long, standard height
Self-aligning for compensation of misalignments	Without self-alignment
Length of runner block	139 mm
Runner block or guide rail	Runner block
Width of runner block	100 mm
Static torsional moment load capacity Mt0	1740 Nm
Dynamic torsional moment load capacity Mt100	1000 Nm
Static longitudinal moment load capacity ML0	1560 Nm
Linear guide type	Ball rail system
Version	Ball rail system
Accuracy class	P - Precise
Dimension B1	105.5 mm
Friction coefficient μ min.	0.002
Model	High-speed ball runner block
Lubrication	Pre-lubricated, preserved
Maximum permissible linear speed vmax	10 m/s
Friction coefficient μ max.	0.003
Dynamic load capacity C50	58700 N
Material (profiled rail systems)	Carbon steel
Preload force	3020 N
Maximum acceleration rate amax	500 m/s²
Dynamic load capacity C100	46600 N
Dynamic longitudinal moment load capacity ML50	1130 Nm
Dynamic longitudinal moment load capacity ML100	900 Nm
Dynamic torsional moment load capacity Mt50	1260 Nm
Dimension T1 min	16 mm
Seal	SS - Standard seal
Permissible ambient temperature (min)	<prefix>-</prefix>10<suffix></suffix> °C
Permissible ambient temperature (max)	<prefix>+</prefix>80<suffix></suffix> °C
Weight	2.25 kg
Permissible ambient temperature (min. ... max.)	-10 °C ... +80 °C
Weight	0.100000
Manufacturer	Bosch Rexroth
Manufacturer Nr.	R200232290
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Norm	DIN ISO 14728-1
Preload	C2
Accuracy class	P - Precision
