Ball runner block KWD-015-SLS-C1-H-0 by Bosch Rexroth, material number R201211307. Size 15, material Corrosion-resistant steel (Resist NR II), accuracy class H - Highly accurate, preload class C1 - Low preload, seal LS - Low-friction seal and lubrication Without lubrication (dry).
Ball runner block KWD-015-SLS-C1-H-0 - Bosch Rexroth R201211307
BOSCH REXROTH
Original product
Net price (excl. VAT)
€135.91
Item
BRR-R201211307
Manufacturer no.
R201211307
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R201211307
Country of originGermany
ConditionNew
Article
BRR-R201211307
Frequently Bought Together
-
This Item:
€135.91
-
Ball runner block KWD-020-BNS-C1-P-1 - Bosch Rexroth R16715122Y
€160.70
-
Ball runner block KWD-025-FNS-C3-X-1 - Bosch Rexroth R16512382Y
€135.20
Total price
Ball runner block KWD-015-SLS-C1-H-0 by Bosch Rexroth, material number R201211307. Size 15, material Corrosion-resistant steel (Resist NR II), accuracy class H - Highly accurate, preload class C1 - Low preload, seal LS - Low-friction seal and lubrication Without lubrication (dry). The dynamic load capacity is 7600 N. The static load capacity is 12100 N. Permissible values are up to 5 m/s travel speed and 500 m/s² acceleration. The weight is 0.2 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 24 mm |
| Pitch T guide rail | 60 mm |
| Ball chain | With ball chain |
| Nominal size | 15 |
| Preload class | C1 - Low preload |
| Static load capacity C0 | 12100 N |
| Height of runner block | 19.9 mm |
| Format | SLS - slimline, long, standard height |
| Self-aligning for compensation of misalignments | Without self-alignment |
| Length of runner block | 72.6 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 34 mm |
| Static torsional moment load capacity Mt0 | 118 Nm |
| Dynamic torsional moment load capacity Mt100 | 73 Nm |
| Static longitudinal moment load capacity ML0 | 93 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | H - Highly accurate |
| Dimension B1 | 53.6 mm |
| Friction coefficient μ min. | 0.002 |
| Model | High-precision ball runner block |
| Lubrication | Without lubrication (dry) |
| Maximum permissible linear speed vmax | 5 m/s |
| Friction coefficient μ max. | 0.003 |
| Dynamic load capacity C50 | 9580 N |
| Material (profiled rail systems) | Corrosion-resistant steel (Resist NR II) |
| Preload force | 150 N |
| Maximum acceleration rate amax | 500 m/s² |
| Dynamic load capacity C100 | 7600 N |
| Dynamic longitudinal moment load capacity ML50 | 73 Nm |
| Dynamic longitudinal moment load capacity ML100 | 58 Nm |
| Dynamic torsional moment load capacity Mt50 | 92 Nm |
| Dimension T1 min | 12 mm |
| Seal | LS - Low-friction seal |
| Permissible ambient temperature (min) | <prefix></prefix>0<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.2 kg |
| Permissible ambient temperature (min. ... max.) | 0 °C ... +80 °C |
| Manufacturer Nr. | R201211307 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
