Ball runner block KWD-015-SLS-C2-H-0 - Bosch Rexroth R201212304

Name: Ball runner block KWD-015-SLS-C2-H-0 - Bosch Rexroth R201212304
Brand: Bosch Rexroth
SKU: BRR-R201212304
Price: 132.54 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Net

€132.54

excl. VAT

Item BRR-R201212304

Manufacturer no. R201212304

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Ball runner block KWD-015-SLS-C2-H-0 by Bosch Rexroth, material number R201212304. Size 15, material Corrosion-resistant steel (Resist NR II), accuracy class H - Highly accurate, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Without lubrication (dry). The dynamic load capacity is 8500 N. The static load capacity is 14000 N. Permissible values are up to 5 m/s travel speed and 500 m/s² acceleration. The weight is 0.2 kg.

Technical data

Friction coefficient μ	0.002 ... 0.003
Height runner block with guide rail	24 mm
Pitch T guide rail	60 mm
Ball chain	Without ball chain (standard)
Nominal size	15
Preload class	C2 - Medium preload
Static load capacity C0	14000 N
Height of runner block	19.9 mm
Format	SLS - slimline, long, standard height
Self-aligning for compensation of misalignments	Without self-alignment
Length of runner block	72.6 mm
Runner block or guide rail	Runner block
Width of runner block	34 mm
Static torsional moment load capacity Mt0	132 Nm
Dynamic torsional moment load capacity Mt100	82 Nm
Static longitudinal moment load capacity ML0	104 Nm
Linear guide type	Ball rail system
Version	Ball rail system
Accuracy class	H - Highly accurate
Dimension B1	53.6 mm
Friction coefficient μ min.	0.002
Model	High-precision ball runner block
Lubrication	Without lubrication (dry)
Maximum permissible linear speed vmax	5 m/s
Friction coefficient μ max.	0.003
Dynamic load capacity C50	10700 N
Material (profiled rail systems)	Corrosion-resistant steel (Resist NR II)
Preload force	680 N
Maximum acceleration rate amax	500 m/s²
Dynamic load capacity C100	8500 N
Dynamic longitudinal moment load capacity ML50	81 Nm
Dynamic longitudinal moment load capacity ML100	64 Nm
Dynamic torsional moment load capacity Mt50	100 Nm
Dimension T1 min	12 mm
Seal	SS - Standard seal
Permissible ambient temperature (min)	<prefix>-</prefix>10<suffix></suffix> °C
Permissible ambient temperature (max)	<prefix>+</prefix>80<suffix></suffix> °C
Weight	0.2 kg
Permissible ambient temperature (min. ... max.)	-10 °C ... +80 °C
Weight	0.100000
Manufacturer	Bosch Rexroth
Manufacturer Nr.	R201212304
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
