Ball runner block NRFG KWD-020-SLS-C0-H-0 by Bosch Rexroth, material number R201289314. Size 20, material Corrosion-resistant steel (Resist NR II), accuracy class H - Highly accurate, preload class C0 - Without preload (clearance), seal SS - Standard seal and lubrication Without lubrication (dry).
Ball runner block NRFG KWD-020-SLS-C0-H-0 - Bosch Rexroth R201289314
BOSCH REXROTH
Original product
Net price (excl. VAT)
€177.78
Item
BRR-R201289314
Manufacturer no.
R201289314
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R201289314
Country of originGermany
ConditionNew
Article
BRR-R201289314
Frequently Bought Together
-
This Item:
€177.78
-
Ball runner block NRFG KWD-030-SKS-C0-H-0 - Bosch Rexroth R201079314
€156.30
-
Ball runner block AL KWD-020-SNS-C1-H-1 - Bosch Rexroth R163281321
€78.44
Total price
Ball runner block NRFG KWD-020-SLS-C0-H-0 by Bosch Rexroth, material number R201289314. Size 20, material Corrosion-resistant steel (Resist NR II), accuracy class H - Highly accurate, preload class C0 - Without preload (clearance), seal SS - Standard seal and lubrication Without lubrication (dry). The dynamic load capacity is 16000 N. The static load capacity is 24400 N. Permissible values are up to 5 m/s travel speed and 500 m/s² acceleration. The weight is 0.45 kg.
Technical data
| Height runner block with guide rail | 30 mm |
|---|---|
| Pitch T guide rail | 60 mm |
| Lubrication | Without lubrication (dry) |
| Ball chain | Without ball chain (standard) |
| Maximum permissible linear speed vmax | 5 m/s |
| Nominal size | 20 |
| Preload class | C0 - Without preload (clearance) |
| Static load capacity C0 | 24400 N |
| Dynamic load capacity C50 | 20200 N |
| Material (profiled rail systems) | Corrosion-resistant steel (Resist NR II) |
| Height of runner block | 25.35 mm |
| Format | SLS - slimline, long, standard height |
| Self-aligning for compensation of misalignments | Without self-alignment |
| Maximum acceleration rate amax | 500 m/s² |
| Dynamic load capacity C100 | 16000 N |
| Dynamic longitudinal moment load capacity ML50 | 240 Nm |
| Dynamic longitudinal moment load capacity ML100 | 190 Nm |
| Dynamic torsional moment load capacity Mt50 | 330 Nm |
| Length of runner block | 91 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 44 mm |
| Static torsional moment load capacity Mt0 | 310 Nm |
| Dynamic torsional moment load capacity Mt100 | 265 Nm |
| Dimension T1 min | 13 mm |
| Static longitudinal moment load capacity ML0 | 230 Nm |
| Linear guide type | Ball rail system |
| Version | Ball rail system |
| Accuracy class | H - Highly accurate |
| Dimension B1 | 65.6 mm |
| Seal | SS - Standard seal |
| Model | NRFG ball runner block |
| Weight | 0.45 kg |
| Manufacturer Nr. | R201289314 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
