Kugelwagen CS KWE-025-FLS-C0-N-1 by Bosch Rexroth, material number R205B29420. Size 25, accuracy class N - Normal, preload class C0 - Without preload (clearance), seal SS - Standard seal and lubrication Pre-lubricated, preserved.
Bosch Rexroth R205B29420. Kugelwagen CS KWE-025-FLS-C0-N-1
BOSCH REXROTH
Original product
Net price (excl. VAT)
€41.29
Item
BRR-R205B29420
Manufacturer no.
R205B29420
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R205B29420
Country of originGermany
ConditionNew
Article
BRR-R205B29420
Frequently Bought Together
-
This Item:
€41.29
-
Bosch Rexroth R205C72320. Kugelwagen CS KWE-030-SNS-C2-H-1
€39.70
-
Front seal 35 BSCL - Bosch Rexroth R205Z31000
€6.49
Total price
Kugelwagen CS KWE-025-FLS-C0-N-1 by Bosch Rexroth, material number R205B29420. Size 25, accuracy class N - Normal, preload class C0 - Without preload (clearance), seal SS - Standard seal and lubrication Pre-lubricated, preserved. The dynamic load capacity is 28000 N. The static load capacity is 44200 N. Permissible values are up to 3 m/s travel speed and 250 m/s² acceleration. The weight is 0.8 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 36 mm |
| Pitch T guide rail | 60 mm |
| Lubrication | Pre-lubricated, preserved |
| Ball chain | Without ball chain (standard) |
| Maximum permissible linear speed vmax | 3 m/s |
| Friction coefficient μ max. | 0.003 |
| Nominal size | 25 |
| Preload class | C0 - Without preload (clearance) |
| Static load capacity C0 | 44200 N |
| Dynamic load capacity C50 | 35300 N |
| Dimension T | 60 mm |
| Height of runner block | 30 mm |
| Format | FLS - flange, long, standard height |
| Maximum acceleration rate amax | 250 m/s² |
| Dynamic load capacity C100 | 28000 N |
| Dynamic longitudinal moment load capacity ML50 | 490 Nm |
| Dynamic longitudinal moment load capacity ML100 | 390 Nm |
| Dynamic torsional moment load capacity Mt50 | 440 Nm |
| Length of runner block | 107.9 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 70 mm |
| Static torsional moment load capacity Mt0 | 550 Nm |
| Dynamic torsional moment load capacity Mt100 | 350 Nm |
| Dimension T1 min | 13 mm |
| Static longitudinal moment load capacity ML0 | 620 Nm |
| Linear guide type | Ball rail system Compact Line |
| Version | Ball rail system |
| Accuracy class | N - Normal |
| Dimension B1 | 79.5 mm |
| Seal | SS - Standard seal |
| Friction coefficient μ min. | 0.002 |
| Model | Compact Line ball runner block |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.8 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Norm | DIN ISO 14728-1 |
|---|---|
| Manufacturer Nr. | R205B29420 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Preload | C0 - light preload |
| Accuracy class | N - Normal |
| Position sensing | No |
