The Bosch Rexroth Compact Line BSCL is a compact, ready-to-install ball rail guidance system for applications with limited installation space. Rail and runner block are supplied matched to each other; the low overall height and favourable width-to-height ratio allow compact designs while still offering high load and moment capacity to ISO 14728-1.
esd.equipment supplies the complete BSCL range in sizes 15 to 45 together with accessories - sheet-metal wipers, seal kits and front wipers - for reliable protection and easy maintenance of the guidance system.
BSCL Compact Line - range overview
| Size | Component | Function |
|---|---|---|
| 15 / 20 | Ball rail CS KSE, runner block | base guide, ready to install |
| 25 / 30 | Sheet-metal wiper | protection against chips and coarse dirt |
| 35 / 45 | Seal kit | front and longitudinal sealing of the block |
| 15-45 | Front wiper / accessories | enhanced protection in harsh environments |
Typical applications: Compact handling axes, electronics and semiconductor manufacturing, medical and laboratory equipment, packaging machinery and automation modules with limited installation space and high demands on smooth running.
