SW Aware Monitor for Single Workstation, Ethernet, with Universal Power Adapter - Desco 770152

A wrist strap that comes loose unnoticed turns a workstation into a risk. The SCS SW Aware Monitor continuously checks the operator's path-to-ground, including the 1 megohm safety resistor, and the worksurface, and immediately sounds a visual and audible alarm when the connection fails or becomes intermittent.

Key benefits

• Impedance Monitoring Technology: stable, true continuous monitoring instead of pulsed testing
• Only 1.2 V applied to the operator, low EOS risk for sensitive components
• Operator test range 500 kilohms to 10 megohms, worksurface below 10 megohms
• Park delay timer and parking snap: 8 seconds to disconnect without a false alarm
• Mat monitor switch, audible alarm adjustable from loud to louder
• Ethernet link to SMP for operator and worksurface pass/fail data

Applications

Single workstations using single-wire wrist straps in assembly, repair and test. Where there is no ESD worksurface, the mat circuit is switched off.

Standards

The wrist strap circuit corresponds to the 0.8 to 1.2 x 10⁶ ohm limit of ANSI/ESD S20.20 with product qualification per ANSI/ESD S1.1. With continuous monitoring, daily wrist strap testing may be omitted.
